Descripción
The CA502-HD wide viewing camera is up to horizontal 200 degree, offers superior image quality in full HD 1080p resolution. Suitable for all types of vehicle applications, including bus, coach, rail, vans, and many more. It features built-in non-LEDs combined super starlight vision, with colorful images even in the darkest night. Clearly captures obstacles and other details outside the vehicle.
| Modelo | CA502-HD |
| Sensor de imagen | CMOS DE 1/2,9 |
| Resolución | 1080P |
| Píxeles efectivos | 1920(H)x1080(V) |
| Tamaño en píxeles | 1,8×1,8μm |
| Ángulo de visión | 200 degrees |
| Grado de impermeabilidad | IP69K |
| A prueba de golpes | 10G |
| Frecuencia de imagen | 25/30fps |
| Visión nocturna | Lente de visión súper starlight |
| Fuente de alimentación | DC9-18V (del monitor de marcha atrás) |
| Audio | Ayuda |
| Calefacción | Ayuda |
| Distancia de visión nocturna | 15m |
| Material de la carcasa | Metal fundido resistente |
| Consumo de energía | 160 mA |
| Peso unitario | 200g |
| Operación Temp | -20℃-70℃， RH95%MAX |
