Description
The CA502-HD wide viewing camera is up to horizontal 200 degree, offers superior image quality in full HD 1080p resolution. Suitable for all types of vehicle applications, including bus, coach, rail, vans, and many more. It features built-in non-LEDs combined super starlight vision, with colorful images even in the darkest night. Clearly captures obstacles and other details outside the vehicle.
| Model | CA502-HD |
| Image Sensor | 1/2.9’’ CMOS |
| Resolution | 1080P |
| Effective Pixels | 1920(H)x1080(V) |
| Pixel Size | 1.8×1.8μm |
| Viewing Angle | 200 degrees |
| Waterproof Rating | IP69K |
| Shockproof | 10G |
| Frame Rate | 25/30fps |
| Night Vision | Super starlight vision lens |
| Power Supply | DC9-18V (from reversing monitor) |
| Audio | Support |
| Auto Heating | Support |
| Night Vision Distance | 15m |
| Housing Material | Heavy-duty cast metal |
| Power Consumption | 160mA |
| Unit Weight | 200g |
| Operation Temp | -20℃-70℃， RH95%MAX |
